Canon IJM153(C) SmartMatt Paper FSC 180g/m² (3" core) 97005553 23.5" 594mm x 30m roll
-
Please contact us on 01905 454 598 for a quote
- Description
- Other available sizes
- Physical Data
- Printing Guidelines for UVGel use
- Application Guidelines for UVGel use
-
Description
Canon IJM153(C) SmartMatt Paper FSC 180g/m²: FSC® certified, bright white, matt barrier-coated paper is a great alternative to photo paper and although optimised for pigment inks is also ideally suited for use with the COLORADO 1650 UVGel Printer. The benefits of this new technology include instant pinning and dot control, high-precision colour matching and consistency as well as being odourless and instant dry on printing with excellent scratch resistance.
Canon IJM153(C) SmartMatt Paper FSC 180g/m² delivers fantastic quality brightness and colour density with the barrier coating preventing curling even with heavy ink absorption. Fast drying properties allow easy handling of your prints.
This product has a 3" core and alternative product widths can be found in the other available sizes tab.
APPLICATIONS:
- Full colour applications
- Technical drawings
- Indoor signage
- Posters
- POP
- Presentations & exhibitions
- Short-term outdoor signage (outdoor inks)
FEATURES:
- High quality, bright white, matt-coated surface
- Excellent print quality with high colour density
- High ink loads without curling
- Longer lasting images
- High white on a homogenous matt surface
- No wet-cockling due to barrier layer
- Suitable for dye & pigment inks
- Fast drying
- Water resistant
- Good lamination properties
- FSC® certified
- 3" core
- Weight: 180g/m²
-
Other available sizes
2" CORE - IFA153:
Canon IJM153 | SmartMatt Paper FSC 180g/m² | 97002887 | 24" 610mm x 30m roll
Canon IJM153 | SmartMatt Paper FSC 180g/m² | 97002888 | 36" 914mm x 30m roll
3" CORE IFA153(C):
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005553 | 23.5" 594mm x 30m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005552 | 24" 610mm x 30m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005555 | 33.1" 841mm x 30m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005554 | 36" 914mm x 30m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005556 | 42" 1067mm x 30m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005557 | 42" 1067mm x 60m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005558 | 50" 1270mm x 30m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005559 | 54" 1372mm x 30m roll
Canon IJM153(C) | SmartMatt Paper FSC 180g/m² | 97005560 | 60" 1524mm x 30m roll
-
Physical Data
-
Printing Guidelines for UVGel use
It is recommended to handle the media with cotton gloves. Make sure that the media comes not into contact with grease, oil, silicon, and dirt to avoid printing defects.
Insert the Tyvek with care in the printer. Incorrect loading can cause skewing or creasing.
It is recommended to calibrate the printer before printing and to make a test print. Print results will vary for different printer ink/toner combinations. Ink/toner restrictions and printer settings have to be set for specific printer-ink/toner combinations to obtain the best results. Canon colour profiles will set optimal restrictions and printer-settings for Canon supported printers.Because of the random/non oriented fibers Tyvek has a certain inhomogeneity across its web. This inhomogeneity may differ per batch and may lead to problems on printers, specifically in cases where Tyvek is exposed to heat.
Due to the nature of the product, high tolerance on thickness, for CrystalPoint only CW700 and CW3700 are recommended.
-
Application Guidelines for UVGel use
Pressure-sensitive adhesive tabs of Tyvek® or Mylar® polyester film wrapped around a sewn seam at each edge will reduce the possibility of edge tear.
It is recommended that the Tyvek banners are stitched hem side up so that the sewing machine comes only in contact with the unprinted side of the banner. Use 1.2 to 2 stitches/cm at low tension to eliminate skipping.
When sewing banners, avoid stitches at or near the edge to reduce the chance for edge-tear. When applying grommets, they should be inserted in double hemmed edges. Corner grommets should be placed where the length and width hems cross, so that the grommet is embedded in four layers.
