Neschen Solvoprint Easy Dot 100 PE Matt 100mic 6042654 63" 1600mm x 50m roll
-
Description
Neschen Solvoprint Easy Dot 100 PE Matt 100mic: Your high-quality solution for latex, UV-curable inks and UV gel inks. The newly improved easy dot® technology produces stunning displays with high colour brilliance and photorealistic prints for indoor and outdoor applications. The dot adhesive guarantees bubble free application and reverse printing allows the inside application on shop windows (clear media). Easy to apply and reposition the base liner provides perfect flatness for easy handling and mounting.
FEATURES:
- 100 µm monomeric PVC white, matt
- “dot-shaped” adhesive coating for easy application and repositioning
- Removable adhesive properties
- Special-PVC for printing with solvent-based, latex, UV gel & UV-curable inks
- Perfect lay flatness, no restrictions with demanding printers
- Suitable for outdoor applications of up to one year
- B1 fire certification according to DIN 4102-1
- M1 fire certification according to NF P 92 503-507
- HP certified for 3rd generation latex inks (L300 series, L500 series & L1500)
- “Easy dot matt”: HP certified for 2nd generation latex inks (L260 & L280)
- High media whiteness for more contrast and natural-looking pastel colours
- High colour brilliance and photorealistic print quality
- Can be applied on smooth and flat surfaces
- No chemical reaction between adhesive and solvent inks
- A slight surface texture can be given due to the dot shaped adhesive
- Car wrapping is not recommended
- The base paper of our release liner comes from a PEFC certified source
- Environment-friendly waterbased adhesive
- 3" core, printside outside
- Also available in 250 m rolls (on 152mm/6" core) for digital-, UV-offset and screen printing
- One-sided self-adhesive, cadmium-free
- Coated with a solvent-free, age-resistant and permanent elastic acrylate adhesive
APPLICATIONS:
- Designed for short to mid-term indoor applications such as trade shows & events
- Outdoor applications up to 1 year
- Durability unprinted up to 2 years
- Not suited for application on lacquered surfaces
- Suitable for (Eco) Solvent-, Latex- and UV-curable inks & UV gels (with solvent inks it's recommended to reduce light colours & total ink amounts)
- For application on a wide range of substrates (on most of the commercially available panels etc.)
- Can be applied to smooth & slightly curved surfaces
PROCESSING & HANDLING:
- Printing profiles with low amounts of light colours are recommended to reach the best printing performance
- Easy to remove from nearly all substrates
- mounted on PVC-surfaces, it can remain residue of adhesive when removing
- The removing of the film from heated surfaces (e.g. shop windows, steel surfaces, etc.) is not recommended, otherwise the adhesive may completely stay on the surface. In such cases we recommend cooling down the material and the surface before removing
- To avoid problems in processing/lamination ensure adequate drying before lamination drying time of min. 24 hours is recommended
- Storage is best to be done in upright position in the original case
- Surfaces must be properly prepared and free of contamination
- Applying by assistance of water is not recommended
- Possibly arising adhesive residues can be removed with help of denatured alcohol
- Stretching should be minimised as much as possible to prevent excessive shrinking
- Shrinking of the edges on monomeric vinyl may occur during storage time
-
Other available sizes
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6034818 | 42" 1067mm x 50m roll
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6030349 | 54" 1372mm x 50m roll
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6034735 | 54" 1372mm x 250m roll
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6042654 | 63" 1600mm x 50m roll
-
Matching components
PRINT MEDIA:
Neschen Solvoprint® easy dot 100 glossy/matt (exclusively this combination is recommended)
PROTECTION FILM:
Neschen filmolux® nippon plus (R9 certified by IFA)
PRINT MEDIA:
Neschen Solvoprint® easy 80 GSP removable
Neschen Solvoprint® easy 80 GSP nolite
Neschen Solvoprint® easy dot 100 glossy/matt (with edge protection)
PROTECTION FILM:
Neschen filmolux® FGS (R9 certified by IFA
-
Related products
MATT FINISH:
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6034818 | 42" 1067mm x 50m roll
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6030349 | 54" 1372mm x 50m roll
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6034735 | 54" 1372mm x 250m roll
Neschen | Solvoprint Easy Dot 100 PE Matt 100mic | 6042654 | 63" 1600mm x 50m roll
GLOSS FINISH:
Neschen | Solvoprint Easy Dot 100 PE Gloss 100mic | 6030348 | 54" 1372mm x 50m roll
Neschen | Solvoprint Easy Dot 100 PE Gloss 100mic | 6034736 | 54" 1372mm x 250m roll
CLEAR FINISH:
Neschen | Solvoprint Easy Dot 100 PE Clear 100mic | 6033494 | 39.4" x 27.6" (100 Sheets)
Neschen | Solvoprint Easy Dot 100 PE Clear 100mic | 6034820 | 42" 1067mm x 50m roll
Neschen | Solvoprint Easy Dot 100 PE Clear 100mic | 6032517 | 54" 1067mm x 50m roll
Neschen | Solvoprint Easy Dot 100 PE Clear 100mic | 6034734 | 54" 1067mm x 250m roll
