Canon imagePROGRAF TM-255 A1 24" MFP with Lm24 Scanner

Name: Canon imagePROGRAF TM-255 A1 24" MFP with Lm24 Scanner
Brand: Canon
SKU: 6238C003AA-LM24-BUNDLE
Price: 2875.14 GBP
Availability: InStock
Rating: 5 (1 reviews)

MPN: 6238C003AA-LM24-BUNDLE

The Canon imagePROGRAF TM-255 A1 24" MFP is a compact print, copy and scan solution with an Lm24 scanner and integrated HDD. Built for CAD, plans, posters and office workflows, the TM-255 delivers professional A1 output in a space-saving multifunction system.

What's Included

Canon TM-255 (HDD) MFP (inc LM24 Scanner), stand, scanner mounting brackets, 480ml ink included, 3 x free Plot it 594mm x 50mtr paper, print head, 3-inch adapter, power cord, and set up guide.

Software included: PosterArtist Lite (web), Printer Driver, Print Plug-In for Office, Quick Utility Toolbox, Canon Pagelayout software, Android and apple mobile print.

£2,875.14 inc VAT

£2,395.95 ex VAT

Would you like to talk to a specialist about this product?

01905 454598 [email protected]

Make the Canon imagePROGRAF TM-255 A1 24″ MFP with Lm24 Scanner even better with one of our great bundles

Lorem ipsum dolor sit amet, consectetur adipiscing elit maximus ultricies nunc in elementum.

CAD Plot 90 Inkjet Paper A1 594mm x 91m – 90gsm

From

£20.34inc VAT

£16.95ex VAT

Select options

CAD Plot Plan Copier Paper A1 594mm x 175m – 80gsm (3″ Cor...

From

£46.68inc VAT

£38.90ex VAT

Add to basket

Canon IJM021 FSC® 24″ 610mm x 50m – 90gsm (Box 3)

From

£38.28inc VAT

£31.90ex VAT

Add to basket

Canon IJM123 Matt Premium Coated 24″ 610mm x 30m – 130gsm

From

£21.60inc VAT

£18.00ex VAT

Select options

Canon IJM260F Instant Dry Photo Paper Gloss FSC® 24″ 610mm x 30m...

From

£46.79inc VAT

£38.99ex VAT

Select options

Canon PF-06 Printhead

From

£394.80inc VAT

£329.00ex VAT

Add to basket

Canon PFI-120BK Photo Black Ink Cartridge – 130ml

From

£70.26inc VAT

£58.55ex VAT

Add to basket

Canon PFI-120C Cyan Ink Cartridge – 130ml

From

£70.26inc VAT

£58.55ex VAT

Add to basket

Canon PFI-120Y Yellow Ink Cartridge – 130ml

From

£70.26inc VAT

£58.55ex VAT

Add to basket

Canon PFI-320C Cyan Ink Cartridge – 300ml

From

£137.65inc VAT

£114.71ex VAT

Add to basket

Canon PFI-320MBK Matte Black Ink Cartridge – 300ml

From

£137.65inc VAT

£114.71ex VAT

Add to basket

Canon PFI-320Y Yellow Ink Cartridge – 300ml

From

£137.65inc VAT

£114.71ex VAT

Add to basket

Canon PFI-320BK Photo Black Ink Cartridge – 300ml

From

£137.65inc VAT

£114.71ex VAT

Add to basket

Canon MC-31 Maintenance Cartridge

From

£65.88inc VAT

£54.90ex VAT

Add to basket

Canon PFI-121M Magenta Ink Cartridge – 130ml

From

£68.39inc VAT

£56.99ex VAT

Add to basket

Canon PFI-321M Magenta Ink Cartridge – 300ml

From

£137.65inc VAT

£114.71ex VAT

Add to basket

Canon CT-08 Cutter Blade

From

£150.96inc VAT

£125.80ex VAT

Add to basket

Canon RH2-28 Roll Holder Set

From

£143.40inc VAT

£119.50ex VAT

Add to basket

USB 2.0 A to B Wide-format Printer Cable 5 m

From

£4.79inc VAT

£3.99ex VAT

Add to basket

Canon imagePROGRAF TM-240 24″ A1 MFP with Lm24 Scanner

From

£2,731.14inc VAT

£2,275.95ex VAT

Select options

Canon imagePROGRAF TM-255 A1 24″ Printer

From

£1,198.80inc VAT

£999.00ex VAT

Select options

Epson SureColor SC-T3100M 24″ A1 MFP Printer

From

£1,248.00inc VAT

£1,040.00ex VAT

Select options

HP DesignJet T830 24″ A1 MFP

From

£1,930.80inc VAT

£1,609.00ex VAT

Select options

All you need to know about the Canon imagePROGRAF TM-255 A1 24″ MFP with Lm24 Scanner

Description Specifications TM-255 Lm24 Install Service Other Related Models

Canon imagePROGRAF TM-255 A1 24″ MFP with Lm24 Scanner

All-in-one print and scan performance for CAD and design studios

The Canon imagePROGRAF TM-255 MFP brings enhanced productivity and precision to your workspace. This compact 24 inch A1 multifunction printer combines fast, accurate printing with integrated Lm24 scanning to create an efficient print, scan and copy workflow for architects, engineers, designers, construction teams and office users.

Building on the TM-240, the TM-255 adds key enhancements including larger 160ml and 300ml ink tank compatibility, an integrated 500GB hard drive for improved job handling, and faster data processing. These upgrades help reduce cost per page and make the Canon imagePROGRAF TM-255 A1 24″ MFP a strong choice for users handling regular CAD drawings, technical documents, plans and poster work.

Canon imagePROGRAF TM-255 MFP key features

The Canon imagePROGRAF TM-255 MFP includes:

Print, scan, and copy: All in one compact system. Combine a high-quality 24” A1 printer with a reliable CIS scanner (Lm24) for seamless digitisation and document reproduction.
Cost-effective printing: Choose from 160ml or 300ml pigment ink tanks to match your print volume. Larger tanks lower the cost per print and minimise cartridge changes.
Built-in 500GB hard drive: Enables secure job storage, spooling, and reprinting, making it ideal for shared office or workgroup environments.
Enhanced security: HDD encryption and user authentication features help protect sensitive project data.
Fast and precise CAD printing: Delivers crisp, detailed lines and sharp text, making it ideal for drawings, blueprints, and schematics.
All-pigment Lucia ink system: Produces durable, water-resistant prints with vibrant colour reproduction and deep blacks, even on uncoated paper.
Supports long rolls: Up to 175m. Accepts both 2″ and 3″ core media, with compatibility for extended rolls, giving you longer print runs and fewer changeovers than other A1 models.
Smart software suite: Comes with Canon Direct Print Plus and SmartWorks for scanning, enabling simple, drag-and-drop workflows and efficient job submission.

Print performance from the Canon imagePROGRAF TM-255

Maximum print width: 24″ (A1 / 610 mm)
Print resolution: Up to 2400 × 1200 dpi
Print speed: A1 CAD print in approx. 24 seconds
Ink colours: Matte Black, Black, Cyan, Magenta, Yellow
Ink capacity: 160ml / 300ml tanks (mix & match as needed)
Borderless printing: Supported (roll only)
Maximum roll length: 175m on 3” core

Lm24 scan and copy features

Scanner model: Lm24 CIS
Scan width: Up to 24” / 610 mm
Scan speed: Up to 6 inches per second (mono)
Resolution: Up to 600 dpi optical
Display: 3.5” colour LCD (scanner)
Copy function: Print directly from scanned originals

Connectivity and Canon workflow software

Interfaces: USB 2.0 High-Speed, Ethernet (10/100/1000Base-T), and Wi-Fi IEEE802.11 b/g/n
Supported operating systems: Windows 10 / 11 (32-bit / 64-bit), and macOS (latest versions)
Software included: Direct Print Plus, Free Layout Plus, SmartWorks MFP Software, PosterArtist Lite (Web), and Device Management Console

Dimensions and power

Dimensions (W × D × H): Approx. 982 × 525 × 245 mm (printer only, without stand or scanner)
Weight: Approx. 36 kg
Noise level: 39 dB(A) or less
Power consumption: 28 W (printing) / 2 W (standby)
Energy certification: EPEAT Gold / ENERGY STAR® Certified

Compact, quiet and efficient A1 MFP

Ink cartridges: PFI-120 (130ml) or PFI-320 (300ml) series, Magenta only Pfi-121, or Pfi-321
Maintenance cartridge: MC-31
Cutter blade: CT-08

Plot it recommendation

If you are a small to mid-volume CAD or office user, the Canon imagePROGRAF TM-255 MFP offers excellent long-term value through low running costs, professional output quality, integrated scanning and secure job handling.

For users with lighter print requirements, the Canon imagePROGRAF TM-240 MFP Lm24 offers a more budget-friendly option. However, for businesses printing regularly, the TM-255 is the smarter long-term investment thanks to its larger ink compatibility, built-in HDD and advanced workflow tools.

You also have the option to extend the standard Canon warranty to 3, 4 or 5 years.

Canon imagePROGRAF TM-255 MFP Lm24 – Technical Specification

Printer specification

Model: Canon imagePROGRAF TM-255
Printer type: 5-colour pigment ink, 24-inch (A1) large format printer
Print technology: Canon Bubblejet on Demand 6-colour integrated type (5 inks)
Print resolution: Up to 2400 x 1200 dpi
Ink type: LUCIA TD pigment ink system (Matte Black, Black, Cyan, Magenta, Yellow)
Ink tank sizes: 160 ml and 300 ml (mix and match supported)
Ink supply: Hot-swap sub-ink system for uninterrupted printing

Print speed:

A1 CAD drawing: approximately 24 seconds (plain paper, fast mode)
Line accuracy: ±0.1% or less
Minimum line width: 0.02 mm
Borderless printing: Yes (roll media only)
Maximum printable length: 18 m (depending on application and OS limitations)

Media handling

Media width: 203.2 mm to 610 mm (8 to 24 inches)
Media type: Plain paper, coated paper, glossy paper, matte paper, tracing paper, and film
Roll feed: Core size: – 2 inch and 3 inch compatible
Roll diameter: Up to 150 mm
Roll length: Up to 175 m (80 gsm on 3 inch core)
Cut sheet feed: Up to A1 size
Media thickness: 0.07 mm to 0.8 mm
Paper feed method: Front loading, front output
Automatic media handling: Automatic roll loading, media type detection, and remaining roll estimation

Scanner specification (Lm24)

Model: Canon Lm24 CIS scanner
Scanner type: Single Sensor CIS (Contact Image Sensor)
Scan width: Up to 610 mm (24 inches)
Media width: Up to 625 mm
Scan length: Up to 8 m
Optical resolution: 600 dpi
Scan resolution: 200 dpi, 300 dpi, 400 dpi, 600 dpi selectable
Scan speed: Monochrome – up to 6 inches per second at 200 dpi. Colour – up to 2 inches per second at 200 dpi
File formats: PDF, JPEG, and TIFF
Display: 3.5 inch colour LCD control panel (scanner)
Copy function: Direct copy from scan to print
Supported scan-to options: USB drive, shared folder, and network location

Controller and software

Processor: Canon L-COA PRO image processor
Memory: 2 GB standard
Hard drive: 500 GB integrated HDD (encrypted)
Supported file formats: HP-GL/2, HP RTL, JPEG, TIFF, and PDF
Software included: Direct Print Plus, Free Layout Plus, PosterArtist Lite (Web version), Device Management Console, Accounting Manager, Media Configuration Tool, SmartWorks MFP (for scan and copy management)

Connectivity and OS compatibility

Interfaces: USB 2.0 High-Speed, Ethernet 10/100/1000Base-T, Wireless LAN IEEE802.11 b/g/n
Supported operating systems: Windows 10, Windows 11 (32-bit and 64-bit), macOS (latest versions), iOS and Android via Canon PRINT App and Apple AirPrint

Print and scan nanagement

Direct printing: Supported via USB, shared network, or web interface
Print job storage: Yes (500 GB HDD for secure job storage)
Secure printing: PIN code access and user authentication supported
Automatic maintenance: Nozzle verification and automatic printhead cleaning

Physical and environmental

Dimensions (W x D x H): Printer only – 982 x 525 x 245 mm. Printer with stand and basket – 982 x 870 x 1060 mm
Acoustic noise level: Approx. 39 dB(A) or less
Power consumption: Printing – 28 W. Standby – 2 W or less
Power supply: AC 100–240 V, 50/60 Hz
Operating environment: Temperature: -15 to 30°C. Humidity – 10% to 80% RH (non-condensing)

Consumables and accessories

Ink cartridges: PFI-120/PFI-121 (M) (130 ml) and PFI-320/PFI-312(M) (300 ml)
Maintenance cartridge: MC-31
Cutter blade: CT-08
Scanner stand kit: Included with Lm24
Media core adapters: Supplied for 2 inch and 3 inch rolls

Delivery and Install Options – Canon TM-255 Lm24

We provide flexible delivery and installation packages to suit your needs – from simple courier drop-offs to full professional setups.

We are a Canon trained service agent with our own in house installation teams.

Install picture – Site office, Scottish Highlands, installed by our tech team

1. Standard Delivery – Free (Mainland UK) – Delivered by courier to a ground-floor location

This is a one-man delivery crew so some assistance may be required to unload. This is also classed as a kerbside delivery, just like all other providers.
Ground floor delivery to door only.
You’re responsible for unpacking, assembly, ink loading, and PC/network connection.

Please ensure there is sufficient access for delivery, as this is classed as a kerbside delivery. There is some flexibility – when it’s possible – to use our own transport. Please contact us with your location and to check suitability. We cover a large proportion of the UK so we maybe able to assist your request.

Mainland UK: Free of charge

Northern Ireland, Scottish Highlands, and Isle of Wight: £149.00

2. Placement Delivery – Delivered to the point of need by a manned crew (ground floor)

Assumes ground floor placement only, or where a suitable, accessible lift is available.
Includes stand assembly and machine fitting.
Packaging is removed from site.
You complete the final setup.

Mainland UK: £199.00

Northern Ireland, Scottish Highlands, and Isle of Wight: £259.00

3. Full Delivery and Installation – Complete install (ground floor)

This is our most complete service for businesses that want everything handled. Like our other delivery options, this service is ground floor only. More complex installs can be easily arranged.
Full placement delivery as stated above.
Complete setup including inks, heads, media loading, and test prints carried out.
Driver installation including standard Windows network connection to one PC, or assistance for IT teams.

For more complex networks, please contact us to confirm suitability.

Mainland UK: £349.00

Northern Ireland, Scottish Highlands, and Isle of Wight: £359.00

For delivery outside these regions, please contact us before purchasing. Orders placed without prior agreement may be refunded.
