HP Designjet Z6600 60" Production Printer F2S71A

HP Designjet Z6610 60" Production Printer 2QU13A Z6600 Series

  • Description

    The HP Multi-dimensional Smart Drop Placement Technology enables the highest quality possible for a 6-ink system while guarding against potential media-feed or drop-placement errors.

    Designed for speed and productivity

    ● Print as fast as 140 m²/hr (1,500 ft²/hr) in fast mode and 20 m²/hr (212 ft²/hr) in high- quality mode.
    ● Cut turnaround times and effortlessly handle large data loads thanks to high
       file-processing power.
    ● Create quality prints at top speed with HP Double Swath Technology and the HP Optical Media Advance Sensor. (OMAS)
    ● Confidently print unattended with heavy media rolls, 775-ml HP ink cartridges and a
       built-in take-up reel.

    High-impact image Quality

    ● Achieve smooth colour tones thanks to HP Multi-Dimensional Smart Drop Placement
    Technology.
    ● Create unique black-and-white prints – three shades of black HP ink deliver rich density
    and smooth transitions.
    ● Offer your customers durable prints that last up to 200 years, using HP Vivid Photo Inks
    ● Print a wide range of jobs – from posters, photos and signs to canvas and backlit prints –
    on many substrates.

    Efficient operation with a 6-ink printing system

    ● Print up to 30% more efficiently using a 6-ink printing system with an optimized
       configuration
    ● Choose how you want to print – send jobs right from preferred design applications or
       through third-party RIPs.
    ● Ensure image quality – and reduce cleaning and waste – using automatic drop    detection and intelligent masking.
    ● Gain colour reliability with HP Professional PANTONE® colour emulation and embedded Adobe® PostScript®/PDF

  • Key Features

     - 320GB Hard drive for high file-processing power

     - HP Optical Media Advance Sensor

     - Three shades of black HP ink

     - Built in take-up reel for unattended printing

     - Media loading table

     - Highest quality possible for a 6 ink system

     - HP Multi-dimensional Smart Drop Placement Technology guards against potential media-feed or drop placement errors

     - Print as fast as 140m2/hr in fast mode and 20m2/hr in high quality mode

     - High capacity 775ml HP ink cartridges

     - Reduced cleaning and waste using Automatic drop detection and intelligent masking for lower cost of ownership

     - Colour reliability with HP Professional PANTONE colour emulation and embedded Adobe PostScript/PDF

  • Technical Specifications

    Print


    Colour images 19.7 m²/hr on glossy media
    Print resolution Up to 2400 x 1200 optimised dpi
    Margins (top x bottom x left x right) Roll: 5 x 5 x 5 x 5 mm
    Technology HP Thermal Inkjet
    Ink types Pigment-based
    Ink colours 6 (1 each cyan, magenta, yellow, light grey, matte black, photo black)
    Ink drop 4 pl (lg, pK), 6 pl (C, M, Y, mK)
    Print cartridge volume delivered 775 ml
    Printhead nozzles 2112
    Printheads 6 (1 each cyan, magenta, yellow, light grey, matte black, photo black)
    Print speed 140 m²/hr
    Line accuracy +/- 0.1%
    Line accuracy note: +/- 0.1% of the specified vector length or +/- 0.2 mm (whichever greater) at 23ºC, 50-60% relative humidity, on A0 HP Matte Film in Best or Normal mode with HP Photo Inks


    Minimum line width 0.02 mm (HP-GL/2 addressable)
    Guaranteed minimum line width 0.067 mm (ISO/IEC 13660:2001(E))
    Maximum print weight 25 kg
    Maximum optical density 4.5 L* min/2.31 D (with HP Premium Instant Dry Photo gloss media with HP Photo Inks)


    Media


    Handling Roll feed; automatic cutter; take-up reel
    Types Bond and coated paper, technical plotter paper, film, photographic paper, proofing paper, backlit, self-adhesive, banner and sign, fabric, fine art printing material including Canvas
    Weight Up to 460 g/m² depending on media type
    Thickness Up to 22 mil


    Memory


    Standard 64 GB (virtual)
    Hard disk Standard, 320 GB
    Connectivity Interfaces(standard) Gigabit Ethernet (1000Base-T); EIO Jetdirect accessory slot, Interfaces(optional) HP Jetdirect EIO print servers
    Print languages(standard) HP-GL/2, HP-RTL, CALS G4
    Print languages(optional) Adobe PostScript® 3; Adobe PDF 1.7; TIFF; JPEG
    Drivers included HP-GL/2, HP-RTL drivers for Windows; PostScript® Windows and Mac drivers with optional PostScript/PDF Upgrade Kit


    Acoustic
    SoundPressure 53 dB(A)
    SoundPower 7.0 B(A)


    Dimensions (wxdxh)
    Printer      2430 x 690 x 1370 mm
    Packaged 2700 x 750 x 1200 mm
    Weight
    Printer 190 kg
    Packaged 251 kg
    Powerconsumption Maximum 420 watts (maximum); 270 watts (printing); < 48 watts (ready); < 5 watts, (sleep); < 0.3 watts (off)


    What's in the box?


    F2S71A HP Designjet Z6600 Production Printer; spindle; printheads; introductory ink
    cartridges; maintenance cartridge; printer stand; take-up reel; 3-in spindle adaptor kit; quick reference guide; setup poster; startup software; power cord. One year on site parts and Labour Warranty (upgradeable)
