Canon imagePROGRAF TA-20 A1 Printer (3659C003AA)

Click the yellow arrows to view multiple buying options...


  • Description

    Canon TA-20 MAIN BANNER

    FAST & FLEXIBLE PRINTING TO MAXIMISE INK & MEDIA USAGE

    Boost your productivity and minimise costs, with a 55ml ink tank designed for smaller print jobs. Innovative imaging technology increases precision and reduces media wastage, with three and four-sided borderless printing on any roll width.

    Canon imagePROGRAF TA-20 has been designed for entry level low volume users, delivering stunning quality it is ideal for Point of Sale, Posters, Graphics as well as CAD drawings for the construction & manufacturing sectors.



    Canon TA-20

    Canon TA-20 poster printing



    With roll fed paper it's able to deliver both A1 & A2 output straight from the single online roll feed which accepts a variety of medias from standard 80 & 90gsm plot paper right through to presentation matte coated, Satin & Gloss photo papers, beyond this plot-IT have a variety of polyprops & self-adhesive which also deliver great output quality and extends the capability of this handy printer.



    The Canon TA-20 small footprint & multiple connectivity options can fit anywhere in your work space choose from USB, LAN & even wi-fi. With noise cancelling technology featured & developed on the Canon TM-200 the TA is one of the quietest A1 printers on the market so it can placed in even the smallest of environments. Also featuring Canon's innovative air feed media handling paper is flat to the platen driving more print accuracy & quality



    Building on other products in the imagePROGRAF range the TA-20 uses Canon Lucia pigment ink & utilises smaller more affordable 55ML ink cartridges as such for low volume users you don't have to tie up lots of money in larger ink cartridges, higher volume users should however consider the lower cost per ML on the Canon TM-200 or the Canon TX-2100. In all instances Canon Lucia Pigment ink delivers water resistant & light fast prints ideal for shop display, sandwich boards & taking building plans on to site.

    Canon TA-20

    You don't need to be an expert in graphic design to benefit from poster or point of sale printing, bundled with the TA-20 is Canon Poster Artist Lite, a free software tool allowing you to easily create posters, quickly & efficiently without the need for either expensive Desktop Publishing software or Graphic Designers.

    Canon TA-20 A1 Printer



    The Canon TA-20 can be supplied with an optional stand to make it a free standing printer, Supplied with print collection basket for hassle free printing, completed prints simply drop in to the basket for colection later.

  • Canon TA-20 Drivers

    Canon imagePROGRAF TA-20 is compatible with the following operating systems (Published as of 01/2020):


    MAC OS:

    • macOS 12 (Monterey)
    • macOS 11 (Big Sur)
    • macOS 10.15 (Catalina)
    • macOS 10.14 (Mojave)
    • macOS 10.13 (High Sierra)
    • macOS 10.12 (Sierra)
    • macOS X 10.11 (El Capitan)
    • macOS X 10.10 (Yosemite)



    WINDOWS:

    • Windows 10 (32-bit)
    • Windows 10 (64-bit)
    • Windows 8.1 (32-bit)
    • Windows 8.1 (64-bit)
    • Windows 7 (32-bit)
    • Windows 7 (64-bit)
    • Windows Server 2016 (64-bit)
    • Windows Server 2012 R2 (64-bit)
    • Windows Server 2012 (64-bit)
    • Windows Server 2008 R2 (64-bit)

  • Our Opinion

    Canon enter what is classed as the Ultra Low Volume Market with the TA-20, Designed for small work groups or light volume use, despite this the TA-20 is like all Canon imagePROGRAF plotters a robust well engineered printer.

    Bringing a new benchmark in pricing to the Canon line up the TA-20 comes in at under £700 + VAT without stand in it's desktop form, the stand and paper catcher basket can be bought separately.

    The ULV market offers entry in to wide-format printing at a low capital investment, however typically the cost per print is higher as ink cartridges tend to be more expensive per ML, the bigger more costly the machine the lower the cost of a cartridge. The imagePROGRAF TA-20 bucks this trend a little with 55ML ink cartridges in all colours at around £37 each compared with other manufacturers who offer 29ML colour inks, however it's slightly bigger brother the TM-200 can use  a choice of 130ML or 300ML inks and when you consider that a 300ML is about £100 and you're nearly getting 6 times more ink at only 3 times the price it might be worth considering the TM as an alternative (Plus it comes with the stand and 650ML of ink out the box - so an immediate saving when all added up)

    The best thing about the Canon ink in this instance is that it is Light Fast & Water resistant, ideal for Construction Drawings as well as Posters & Graphics / infographics for retail applications and venues where poster messaging is critical. Although not a 12 colour printer it can also produce a good quality photograph as well. It allows small businesses to make a low investment cost and deliver great quality output & as Canon also include some easy to use creation poster software you don't need to be a graphic designer to create great graphics.

    If your likely to be  a light volume user then we'd recommend the TA-20 as a great introduction in to wide-format printing without a large upfront financial outlay.

  • Tech Specs

    • PRINTER TYPE: 5 colors 24”/610mm
    • PRINT TECHNOLOGY: Canon Bubblejet on Demand 6 colours integrated type (6 chips per print head x 1 print head)
    • PRINT RESOLUTION: 2,400 x 1,200 dpi
    • NUMBER OF NOZZLES: 15,360 nozzles (MBK 5,120 nozzles, Other Colors 2,560 nozzles each)
    • LINE ACCURACY: ±0.1% or less User adjustments necessary. Printing environment and media must match those used for the adjustments. CAD paper required: Plain paper, CAD tracing paper, coated paper, CAD translucent matte film only
    • NOZZLE PITCH: 1,200dpi (2 lines)
    • INK DROPLET SIZE: minimum 5 pl per colour
    • INK CAPACITY: Sales Ink: 55ml Bundled Starter Ink: 55ml (2 x MBK, 1 x BK,C,M,Y)
    • INK TYPE: Pigment inks - Matte Black, Black, Cyan, Magenta, Yellow
    • PRINTER LANGUAGES: SG Raster (Swift Graphic Raster),HP-GL/2, HP RTL, JPEG (Ver. JFIF1.02)
    • STANDARD INTERFACES: USB B Port: Hi-Speed Ethernet: IEEE 802.3 10base- T/IEEE 802.3u 100base-TX/IEEE 802.3ab 1000base-T/IEEE 802.3x Full Duplex Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b * Please refer to user manual how to activate /deactivate the wireless LAN
  • Dimensions & Weight

    PHYSICAL DIMENSIONS WxDxH (mm) and Weight (Kg):

    • 982 x 748 x 438 mm
    • 37 kg (including Roll Holder Set, excluding ink and print head)
    • 982 x 870 x 1059 mm(with stand & basket opened)
    • 46kg (including Stand, Roll Holder Set, excluding ink and print head)



    PACKAGES DIMENSIONS WxDxH (mm) and Weight (Kg):

    • Printer (Main unit with pallet): 1147 x 874 x 542 mm, 49 kg Stand + Basket (SD-24): 1055 x 824 x 268 mm, 16kg
